Oilless Vacuum Pumps

Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump

Introduction

Xunwande



The Small Vacuum Pump is an essential machine for laboratories, medical facilities, and households. This portable and easy-to-use vacuum pump boasts a powerful 60-liter/minute suction capacity, making it ideal for a wide range of applications. With an oil-free design, this lab vacuum pump operates cleanly and quietly, ensuring a safe and comfortable working environment.



Uniquely, the Xunwande Small Vacuum Pump is an oil less medical mute pump. Unlike conventional vacuum pumps that require regular oil changes and produce loud operating noise, this pump runs silently without creating any hazardous emissions. This also means that there is no need for maintenance, providing further convenience and cost-efficiency.



This pump is built to meet industrial-grade standards, combining high-quality materials and advanced technology. Its compact and lightweight design allows users to take this mini vacuum pump anywhere with ease. Whether Xunwande you need it to operate in a lab, clinic, or office setting, this portable pump delivers reliable and efficient performance at all times.



Using the Xunwande Small Vacuum Pump is a breeze. This product features a user-friendly interface, with a straightforward operation that even first-time users can navigate easily. Simply plug it in, turn it on, and the machine starts to work immediately - no preheating or assembly required. Meanwhile, its multiple safety features, such as an automatic power-off function, prevent accidents from occurring.



The benefits of the Xunwande Small Vacuum Pump extend beyond its technical features. With its sleek and modern design, it adds style and functionality to any workspace. Its compact size means it can be placed on any workbench, desk, or shelf without taking up too much space.



The Xunwande Small Vacuum Pump is a reliable, efficient and user-friendly vacuum pump. Its oil less and medical mute design, together with its 60L/min suction capacity, makes it the ideal choice for a wide range of applications. As a product that delivers premium performance, durability and convenience, it is a must-have for all laboratories, medical facilities, hobbyists and householders seeking the best-in-class product in the market. Get yours today.




Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump manufacture
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump supplier
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump manufacture
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump manufacture
Performance Data
Head configuration
Pressure parallel flow
Pressure parallel flow


Nominal voltage/frequency
110V/60Hz/1
220V/50Hz/1


Maximum Current
2.2 A
1.1 A


Maximum power
200 W
200 W


Maximum flow
60 L/min
60 L/min


Maximum vacuum degree
-88 KPa
-88 KPa


Speed at rated load
1650 rpm
1400 rpm


Noise
<53 db="">
<53 db="">


Maximum pressure restart
0 PSI
0 PSI


Electrical Data
Motor type [Capacitance]
P. S. C(14uF)
P. S. C(6.5uF)


Motor insulation class
B
B


Thermal switch [Open temperature]
Thermally protected(145℃)
Thermally protected(145℃)


Line lead wire color, gauge
White(hot), black(neutral), 20 AWG
Brown(hot), blue(neutral), 20AWG


Capacitor lead wire color, gauge
Blue, blue, 18 AWG
Black, black, 18 AWG


General Data
Operating ambient air temperature
50°to 104°F(10℃ to 40℃)
50°to 104°F(10℃ to 40℃)


Safety certification
ETL
ETL


Net weight
4 Kg
4Kg


Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump manufacture
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump factory
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump supplier
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump details
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump manufacture
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump factory
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump supplier
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump factory
Small vacuum pump 60L/min Portable Oil Free Lab Vacuum Pump Oilless Medical Mute Pump factory
FAQ
01 Are you manufacturer or trading company?
We are a multi specialty supplier, located in Changzhou city, Jiangsu province andSuqian city, Jiangsu province.
02 Can we use our own Logo and design?
Yes, we supply OEM service and customized design, DIY your carton and put your logo or brand on the compressor. We'll provide 100%qualified products to support your brand.
03 Can I buy the sample to test?
We are pleased to send the samples for your evaluation, And the samples cost can be refundable when your order is bulk order.
04 Do you have test records of every pump?
We will inspect products three times before shipment and every pump have the test records. We will keep these test records to our quality traceability system about 3-5 years.
05 To ask a quote, what information should I provide and when will i get it?
Please offer the product type, quantity and specification of the products such as voltage, power, air tank capacity and etc. Then we will reply your inquiry within 2-3 hours.
06 Do you sale the accessories of the compressor?
Yes, We provide bearing, cup seal capacitor and etc Pleasae feel free to contact if there's additional you needs.
