Oilless Vacuum Pumps

Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump

Introduction

Xunwande



The Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump is a remarkable product from that is perfect for a wide range of industrial applications. This AC Electric Micro Air Sample Oilless Air Vacuum Pump has been designed to offer reliable and efficient performance, making it a top choice for many people in different industries.



This Oilless piston pump is highly regarded for its quiet operation. It is an excellent choice for anyone who wants to run a pump smoothly without causing any disturbance to the surrounding environment. Whether you need to run the pump in a workshop, laboratory, or other sensitive areas, this pump from Xunwande will offer you an ideal solution.



The Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump is easy to operate and maintain, making it a great choice for those who are looking for a user-friendly pump. It has a simple design that allows for quick and easy installation and Xunwande removal, so you can carry out your work more efficiently. This pump also features a compact and lightweight design that makes it very portable, so you can easily move it from one location to another.



One of the most impressive features of this pump is its top-notch performance. The Oilless piston pump is capable of providing a maximum flow rate of 23L/min, making it suitable for a wide range of applications. Whether you need to move air or sample oil, this pump will deliver excellent performance every time.



The Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump is also very versatile, thanks to its compatibility with both 220V and 110V AC power supplies. This makes it easy to use in different settings, regardless of the power requirements.



the Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump from Xunwande is a top-quality product that offers reliable, efficient, and versatile performance. Whether you need to use it for industrial applications, scientific research, or any other purpose, this pump is an excellent investment that will serve you well for years to come. So, if you are looking for a reliable and efficient Oilless piston pump, this product from Xunwande is definitely worth considering.




Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump factory
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump manufacture
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump manufacture
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump factory
Performance Data
Head configuration
Pressure parallel flow
Pressure parallel flow


Nominal voltage/frequency
110V/60Hz/1
220V/50Hz/1


Maximum Current
1.2 A
0.6A


Maximum power
100 W
100 W


Maximum flow
22L/min
22 L/min


Maximum vacuum degree
-93KPa
-93KPa


Speed at rated load
1650 rpm
1400 rpm


Noise
<53 db="">
<53 db="">


Maximum pressure restart
0 PSI
0 PSI


Electrical Data
Motor type [Capacitance]
P. S. C(20uF)
P. S. C(10uF)


Motor insulation class
B
B


Thermal switch [Open temperature]
Thermally protected(145℃)
Thermally protected(145℃)


Line lead wire color, gauge
White(hot), black(neutral) 18AWG
Brown(hot), blue(neutral) 18AWG


Capacitor lead wire color, gauge
Blue, blue, 18 AWG
Black, black, 18 AWG


General Data
Operating ambient air temperature
50°to 104°F(10℃ to 40℃)
50°to 104°F(10℃ to 40℃)


Safety certification
ETL
ETL


Net weight
2.4 Kg
2.4Kg


Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump factory
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump details
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump factory
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump supplier
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump details
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump factory
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump details
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump supplier
Quiet Double-Head Electric Micro 220V/110V AC Oilless Piston Pump AC Electric Micro Air Sample Oilless Air Vacuum Pump supplier
FAQ
01 Are you manufacturer or trading company?
We are a multi-specialty supplier, located in Changzhou city, Jiangsu province andSuqian city, Jiangsu province.
02 Can we use our own Logo and design?
Yes, we supply OEM service and customized design, DIY your carton and put your logo or brand on the compressor. We'll provide 100%qualified products to support your brand.
03 Can I buy the sample to test?
We are pleased to send the samples for your evaluation, And the samples cost can be refundable when your order is bulk order.
04 Do you have test records of every pump?
We will inspect products three times before shipment and every pump have the test records. We will keep these test records to our quality traceability system about 3-5 years.
05 To ask a quote, what information should I provide and when will i get it?
Please offer the product type, quantity and specification of the products such as voltage, power, air tank capacity and etc. Then we will reply your inquiry within 2-3 hours.
06 Do you sale the accessories of the compressor?
Yes, We provide bearing, cup seal capacitor and etcPleasae feel free to contact if there's additional you needs.
