The Xunwande’s 40L/min 160W small silent oil free vacuum pump is a high-pressure mini vacuum pump that is perfect for medical use. This product is designed to provide reliable and efficient suctioning power, while remaining lightweight, compact, and easy to handle.
The vacuum pump is designed with an oil-free piston, which helps to ensure that it operates smoothly and quietly. This is an important feature for medical use, as it means that the pump will not disrupt the peace and quiet of a hospital or medical facility.
The Xunwande’s vacuum pump is also built with a sturdy aluminum alloy casing that provides excellent durability and protection against the wear and tear of daily use. The casing is rust-resistant and scratch-resistant, ensuring that the vacuum pump will look and perform like new for years to come.
In terms of performance, the Xunwande’s vacuum pump has a powerful 160W motor that is capable of producing suction at a rate of 40L/min. This makes it ideal for use in a range of medical applications, including surgical procedures, laboratory work, and clinical settings.
Another key feature of the Xunwande’s vacuum pump is its high-pressure capability, which enables it to suction fluids and liquids quickly and efficiently. It has a maximum vacuum suction of -85kpa, which means that it can handle even the most challenging tasks with ease.
One of the standout features of the Xunwande’s vacuum pump is its quiet operation. This is achieved through the use of a specially designed noise-dampening system, which minimizes any vibration or noise created by the pump. This is especially important in medical settings, where noise and vibration can be a major distraction.
The Xunwande’s 40L/min 160W small silent oil free vacuum pump is an excellent choice for anyone in need of a reliable, high-pressure mini vacuum pump for medical use. With its compact size, lightweight design, and efficient performance, it is an excellent investment for hospitals, clinics, and medical professionals
Performance Data | ||||
Head configuration | Pressure parallel flow | Pressure parallel flow | ||
Nominal voltage/frequency | 110V/60Hz/1 | 220V/50Hz/1 | ||
Maximum Current | 1.7 A | 0.85 A | ||
Maximum power | 160 W | 160 W | ||
Maximum flow | 40 L/min | 40 L/min | ||
Maximum vacuum degree | -97 KPa | -97 KPa | ||
Speed at rated load | 1650 rpm | 1400 rpm | ||
Noise | <53 db=""> | <53 db=""> | ||
Maximum pressure restart | 0 PSI | 0 PSI | ||
Electrical Data | ||||
Motor type [Capacitance] | P.S.C(9uF) | P.S.C 4.5uF | ||
Motor insulation class | B | B | ||
Thermal switch [Open temperature] | Thermally protected 145℃ | Thermally protected 145℃ | ||
Line lead wire color, gauge | White(hot), black(neutral), 20 AWG | Brown(hot), blue(neutral), 20AWG | ||
Capacitor lead wire color, gauge | Blue, blue, 20 AWG | Black, black, 20 AWG | ||
General Data | ||||
Operating ambient air temperature | 50°to 104°F(10℃ to 40℃) | 50°to 104°F - 10℃ to 40℃ | ||
Safety certification | ETL | ETL | ||
Net weight | 3.5 Kg | 3.5 Kg | ||
FAQ |
01 Are you manufacturer or trading company |
We are a multi specialty supplier, located in Changzhou city, Jiangsu province and Suqian city, Jiangsu province. |
02 Can we use our own Logo and design |
Yes, we supply OEM service and customized design, DIY your carton and put your logo or brand on the compressor. We'll provide 100%qualified products to support your brand. |
03 Can I buy the sample to test |
We are pleased to send the samples for your evaluation, And the samples cost can be refundable when your order is bulk order. |
04 Do you have test records of every pump |
We will inspect products three times before shipment and every pump have the test records. We will keep these test records to our quality traceability system about 3-5 years. |
05 To ask a quote, what information should I provide and when will i get it |
Please offer the product type, quantity and specification of the products such as voltage, power, air tank capacity and etc. Then we will reply your inquiry within 2-3 hours. |
06 Do you sale the accessories of the compressor |
Yes, we provide bearing, cup seal capacitor and etc. Pleasae feel free to contact if there's additional you needs. |
