The 380w oil-free vacuum pump is a must-have for laboratory and medical equipment. This portable piston vacuum pump head delivers exceptional performance with a noiseless operation. The pump is built with state-of-the-art technology that makes it oil-free, providing a clean and safe working environment for users.
At just 98Kpa, this vacuum pump is perfect for use with delicate and sensitive laboratory equipment. The compact and lightweight design of the vacuum pump makes it easy to carry and transport to different locations, allowing you to use it wherever you need it.
The Xunwande 380w oil-free vacuum pump is incredibly durable, built to withstand tough laboratory conditions. The pump head is made from high-quality materials that are resistant to corrosion, ensuring that it remains in excellent condition for extended periods. Additionally, the pump is designed with a stable base, making it sturdy and stable during use.
This vacuum pump is perfect for use in the medical industry, as it delivers exceptional performance while remaining quiet. The Xunwande pump head is designed to run smoothly without any disturbing noise, allowing medical professionals to concentrate on their work. Furthermore, the oil-free technology of this vacuum pump ensures that it does not pollute the air during use.
The Xunwande 380w oil-free vacuum pump features a user-friendly design that makes it easy to operate. The pump comes with a simple control panel that allows for easy adjustments to the vacuum pressure. The control panel also displays all necessary information such as vacuum pressure and operating time.
The Xunwande 380w oil-free vacuum pump is a highly efficient, reliable, and low-noise device that is ideal for use in both laboratory and medical settings. Its compact and lightweight design, along with its oil-free technology, makes it a valuable asset in any work environment. It is a top-quality product that offers excellent value for money and comes highly recommended by professionals in the field. Get your Xunwande 380w oil-free vacuum pump today and enjoy its exceptional performance and longevity.
Performance Data | ||||
Head configuration | Pressure parallel flow | Pressure parallel flow | ||
Nominal voltage/frequency | 110V/60Hz/1 | 220V/50Hz/1 | ||
Maximum Current | 4 A | 2 A | ||
Maximum power | 380 W | 380 W | ||
Maximum flow | 80L/min | 80L/min | ||
Maximum vacuum degree | -98KPa | -98 KPa | ||
Speed at rated load | 1650 rpm | 1400 rpm | ||
Noise | <55 db=""> | <55 db=""> | ||
Maximum pressure restart | 0 PSI | 0 PSI | ||
Electrical Data | ||||
Motor type [Capacitance] | P. S. C(35uF) | P. S. C(12uF) | ||
Motor insulation class | B | B | ||
Thermal switch [Open temperature] | Thermally protected(145℃) | Thermally protected(145℃) | ||
Line lead wire color, gauge | White(hot), black(neutral), 18AWG | Brown(hot), blue(neutral), 18AWG | ||
Capacitor lead wire color, gauge | Blue, blue, 18 AWG | Black, black, 18 AWG | ||
General Data | ||||
Operating ambient air temperature | 50°to 104°F(10℃ to 40℃) | 50°to 104°F(10℃ to 40℃) | ||
Safety certification | ETL | ETL | ||
Net weight | 8.5 Kg | 8.5 Kg | ||
FAQ |
01 Are you manufacturer or trading company? |
We are a multispecialty supplier, located in Changzhou city, Jiangsu province andSuqian city, Jiangsu province. |
02 Can we use our own Logo and design? |
Yes, we supply OEM service and customized design, DIY your carton and put your logo or brand on the compressor. We'll provide 100%qualified products to support your brand. |
03 Can I buy the sample to test? |
We are pleased to send the samples for your evaluation, And the samples cost can be refundable when your order is bulk order. |
04 Do you have test records of every pump? |
We will inspect products three times before shipment and every pump have the test records. We will keep these test records to our quality traceability system about 3-5 years. |
05 To ask a quote, what information should I provide and when will i get it? |
Please offer the product type, quantity and specification of the products such as voltage, power, air tank capacity and etc. Then we will reply your inquiry within 2-3 hours. |
06 Do you sale the accessories of the compressor? |
Yes, We provide bearing, cup sealcapacitor and etcPleasae feel free to contact if there's additional you needs. |
