-88Kpa 60L/min small vacuum pump piston vacuum pump silent small electric portable mini us general air compressor parts

Xunwande

Introducing the -88Kpa 60L/min small vacuum pump, a powerful and compact solution for all your vacuum needs. Whether you're a professional mechanic or simply looking for a handy tool to keep around the house, this vacuum pump is perfect for a variety of applications.

With a powerful -88Kpa vacuum and a maximum flow rate of 60L/min, this piston vacuum pump provides reliable and efficient performance without taking up much space. Its small size makes it easy to store and even easier to transport, making it ideal for use on the job site or in the garage.

But don't let its small size fool you – this silent small electric portable mini pump from Xunwande is a true workhorse. Its durable construction and precision engineering allow it to provide years of reliable service, even in challenging environments.

In fact, this vacuum pump is so versatile that it can be used for a wide range of tasks. Need to pull a vacuum on your air conditioning system? No problem. Want to evacuate fluids from your brake lines? This pump can handle that too. With its high flow rate and powerful vacuum, it's Xunwande perfect for a variety of automotive, industrial, and home DIY applications.

And because it's a Xunwande product, you know you're getting quality you can trust. From the precision machining to the careful selection of materials, this pump is built to last. Plus, with a wide range of available replacement parts – including US General Air Compressor parts – it's easy to keep your pump running smoothly and efficiently.

So if you're looking for a powerful, reliable, and portable vacuum pump, the Xunwande -88Kpa 60L/min small vacuum pump is the perfect choice. With its robust construction, versatile application possibilities, and quality you can trust, you can be confident that this pump will be a valuable addition to your tool collection for years to come.

Performance Data
Head configuration	Pressure parallel flow	Pressure parallel flow
Nominal voltage/frequency	110V/60Hz/1	220V/50Hz/1
Maximum Current	2.2 A	1.1 A
Maximum power	200 W	200 W
Maximum flow	60 L/min	60 L/min
Maximum vacuum degree	-88 KPa	-88 KPa
Speed at rated load	1650 rpm	1400 rpm
Noise	<53 db="">	<53 db="">
Maximum pressure restart	0 PSI	0 PSI

Electrical Data
Motor type [Capacitance]	P. S. C(14uF)	P. S. C(6.5uF)
Motor insulation class	B	B
Thermal switch [Open temperature]	Thermally protected(145℃)	Thermally protected(145℃)
Line lead wire color, gauge	White(hot), black(neutral), 20 AWG	Brown(hot), blue(neutral), 20AWG
Capacitor lead wire color, gauge	Blue, blue, 18 AWG	Black, black, 18 AWG

General Data
Operating ambient air temperature	50°to 104°F(10℃ to 40℃)	50°to 104°F(10℃ to 40℃)
Safety certification	ETL	ETL
Net weight	4 Kg	4Kg

FAQ

01 Are you manufacturer or trading company?

We are a multi specialty supplier, located in Changzhou city, Jiangsu province andSuqian city, Jiangsu province.

02 Can we use our own Logo and design?

Yes, we supply OEM service and customized design, DIY your carton and put your logo or brand on the compressor. We'll provide 100%qualified products to support your brand.

03 Can I buy the sample to test?

We are pleased to send the samples for your evaluation, And the samples cost can be refundable when your order is bulk order.

04 Do you have test records of every pump?

We will inspect products three times before shipment and every pump have the test records. We will keep these test records to our quality traceability system about 3-5 years.

05 To ask a quote, what information should I provide and when will i get it?

Please offer the product type, quantity and specification of the products such as voltage, power, air tank capacity and etc. Then we will reply your inquiry within 2-3 hours.

06 Do you sale the accessories of the compressor?

Yes, We provide bearing, cup seal capacitor and etcPleasae feel free to contact if there's additional you needs.
